- Patented High-Rail System allowing for speeds in excess of 20 mph
- 2.1 mph (low) / 3.4 (high) mph Off-Track Speed
- Internal Wet Disk Axle Braking System
- Life-me JD Link Telematics Subscription
- 500 hr Engine Service Intervals
- Serviceable by the Nationwide John Deere Dealer Network
- Low High-Rail Center of Gravity
Key Features
Specifications
STANDARD SPECIFICATIONS
- John Deere PowerTechTM PVS 6.8 L
- EPA Final Tier 4/EU Stage IV
- 140 kW (188 hp) at 2,100 rpm
- 6 Cylinder 6.8 L (415 cu. in.)
- 2 Variable-Displacement Hyd Pumps
- 224 L/m (59.2 gpm) x 2 Max Hyd Flow
- 24 Volt – 300 Amp Alternator
RAILAVATOR SPECIFICATIONS
- Hydraulically Powered High Rail Gear
- In-Cab Touch Screen Control Center
- Beacon
- 24V to 12V Converter
- Pattern Changer
- Battery Disconnect
- Front & Rear Auxiliary Lights
- Fire Extinguisher
- Remote Oil Drain
- Window Guards
- Camera System (for rail mounting)
- Nonmetallic Soft Pads
- 24″ Rail Wheels
- HD-1 Axles With Oversized Bearings
Dimensions and Weights
Top Level Specs
Operating Weight
68.540 lbs (without attachments)
Arm Digging Force (11'10" Arm)
SAE 25,220 lbs ISO 25,628 lbs
Bucket Digging Force
SAE 36,869 lbs ISO 42,489 lbs
Dimensions - 11'10" Arm
A: Maximum Reach
35'10"
A1: Maximum Reach at Ground Level
35'03"
B: Maximum Digging Depth
25'
B1: Max Digging Depth 8' Flat Bottom
24'05"
C: Maximum Cutting Height
34'08"
D: Maximum Dumping Height
24'10"
E: Minimum Swing Radius
11'03"
F: Maximum Vertical Wall
22'01"
Overall Dimensions with Rail Gear
A: Overall Length (without rail gear)
34'02"
B: Overall Height
10'04"
C: Tail Swing Radius
10'04"
D: Distance Between Idler/Sprocket CL
12'07"
E: Undercarriage Length
15'03"
F: Counterweight Clearance
3'7"
G: Upperstructure Width
9'06"
H: Cab Height
9'11"
I: Track Width
32"
J: Gauge Width
8'06"
K: Ground Clearance (without rail gear)
18"
L: Overall Width (32" Pads)
11'01"
Refill Capabilities
Fuel Tank 132 gal
Diesel Exhaust Fluid 9.3 gal
Cooling System 6 gal
Engine Oil with Filter 5.2 gal
Hydraulic Tank 39 gal
Hydraulic System 63 gal
Swing Drive 7.5 qt
Gearbox Propel (each) 6.5 qt
Gearbox Pump Drive 1.2 qt
