- Patented High-Rail System allows speeds in excess of 20 mph
- Hydraulically Expandable Undercarriage to allow straddling of track
- 1.9 mph (low) /3.1 (high) mph Off-Track Speed
- Spring Applied/Hydraulically released dry shoe brakes
- 500 hr Engine Service Intervals
- Low High-Rail Center of Gravity
- Serviceable by the Nationwide John Deere Dealer Network
Key Features
Specifications
STANDARD SPECIFICATIONS
- Yanmar 4TNV98CT
- EPA Final Tier 4/EU Stage IV
- 50.4 kW (67. 6 hp) at 2,000 rpm
- 4 Cylinder 3.3 L (202 cu. in.)
- 3 Variable-Displacement Axial- Piston Pumps
- 2X72+56L/m(2×19)+15gpm) 24 Volt – 60 Amp Alternator
RAILAVATOR SPECIFICATIONS
- 2-Speed Hydraulically Powered High Rail Gear 4 Independent Drives in each Wheel
- 16” Rail Wheels
- In-Cab Touch Screen Control Center Beacon
- 24V to 12V Converter
- Pattern Changer
- Battery Disconnect
- Front & Rear Auxiliary Lights
- Fire Extinguisher
Dimensions and Weights
Top Level Specs
Operating Weight
20,700 lbs (without attachments)
Arm Digging Force (6'11")
ISO 7,936 lbs
Bucket Digging Force
ISO 13,264 lbs
Dimensions - 6'11" Arm
A: Maximum Cutting Height
23'07"
B: Maximum Dumping Height
16'10"
C: Maximum Digging Depth
14'10"
D: Maximum Digging Reach
24'10"
E: Minimum Swing Radius
08'10"
F: Tail-Swing Radius
05'03"
Overall Dimensions with Rail Gear
A: Overall Length
11'06"
B: Overall Height in Transport Position
8'03"
C: Undercarriage Width (narrowed)
8'06"
C1: Undercarriage Width (wide)
9'10”
D: Rear-End Length/Swing Radius
5’03”
E: Sprocket Center to Idler Center
7’06”
F: Undercarriage Length
9'06"
G: Counterweight Clearance
28"
H: Cab Height
8’03”
I: Ground Clearance
14"
J: Upperstructure Width
7'05"
K: Gauge Width
5’09“
L: Blade Lift Height
19”
M: Blade Cut Below Grade
16”
N: Blade Lift Angle
26 deg
O: Track Width
18”
Refill Capabilities
Fuel Tank 33 gal
Cooling System 3.5 gal
Engine Oil with Filter 3.2 gal
Hydraulic Tank 14 gal
Hydraulic System 26 gal
Propel Gearbox (each) 1.3 qt
